PRODUCT INFORMATION
Overview & application
1. Product Introduction | ODMS Submersible Flow Propeller
The ODMS Submersible Flow Propeller is designed to generate directional water circulation and promote mixing in wastewater treatment tanks. Driven by a submerged motor and propeller, it moves liquid through the treatment zone, helps reduce stagnant areas and keeps suspended solids in motion under suitable operating conditions.
It is commonly used in anoxic tanks, anaerobic tanks, activated sludge systems, oxidation ditches and equalization tanks. By promoting liquid circulation and contact between wastewater and biomass, the flow propeller supports mixing in biological treatment processes without serving as an aeration device.
Available configurations can be selected according to tank dimensions, water depth, required flow pattern, liquid characteristics and installation conditions.
2. Submersible Flow Propeller Performance Characteristics
1). The submersible flow ejector has a compact structure, small size and light weight.
2). Simple operation and maintenance, convenient and quick installation, and long service life.
3). The blade has a self-cleaning function to prevent entanglement and blockage of debris.
4). It can substantially lower energy consumption, with an aerating system.
5). It can protect motors.
6). Mechanical sealing elements are good in corrosion resistance.
7). It is used for aeration tanks and anaerobic tanks of industrial and urban sewage treatment plants, and can also be used for creating water flows at the nitration, denitrification and dephosphorization stages of water circulation machines in tanks.
3. Where Is the Submersible Flow Propeller Used?
Designed for Mixing and Flow Generation in Wastewater Treatment
The submersible impeller is used to create controlled water movement in wastewater treatment tanks, supporting mixing and circulation in aeration, anaerobic, nitrification, denitrification and phosphorus removal processes.
01｜Aeration Tanks : Maintain effective circulation and mixing.
02｜Anaerobic Tanks : Promote uniform mixing without excessive aeration.
03｜Denitrification Tanks : Create stable internal circulation for biological treatment.
04｜Phosphorus Removal Tanks : Support uniform mixing and process conditions.
4. Submersible Flow Propeller Technical Parameter
5. Engineered for Reliable Wastewater Mixing
01｜Self-Cleaning Impeller
The blade design helps reduce debris entanglement and blockage during operation.
02｜Low Energy Consumption
Designed to support efficient mixing and flow generation with reduced energy demand.
03｜Compact Installation
Compact structure and lightweight design simplify installation and maintenance.
04｜Corrosion-Resistant Sealing
Mechanical sealing components provide corrosion resistance for demanding wastewater environments.
05｜Long Service Life
Designed for reliable long-term operation with simplified maintenance.
CTA: Discuss Your Project Requirements
6. Making Equipment Procurement More Reliable
From equipment selection and critical components to pre-shipment verification, ODMS focuses on the details that matter to long-term operation and reliable project delivery.
72H｜full-load reliability verification
Applicable equipment is verified under operating conditions before delivery.
100%｜Key Component Traceability
Key materials, critical components and electrical configurations are documented for traceability.
GLOBAL BRANDS ｜Proven Component Brands
Critical components from proven brands are selected according to equipment and project requirements.
FULL-PROCESS｜Full-Process Technical Support
Technical support throughout key project stages, from equipment selection and technical clarification to installation, commissioning and ongoing operation.
Selection → Technical Clarification → Delivery → Commissioning → Operational Support
